Case Studies of Industrial Equipment Solutions
Electric Instant Water Heater with Vacuum Bottle Structure
The entire tank of the electric instant water heater is covered with a vacuum jacket (double-walled, vacuum structure) to effectively retain heat. The structure contributes to saving energy.
Development background
Tiger Corporation co-developed an electric Instant Water Heater with TOTO Ltd. The electric instant water heater was designed to be installed in a washstand. The tank is covered with a stainless steel vacuum jacket to increase the heat-retaining performance. This helps reduce the energy required to retain heat, achieving eco-friendliness. The vacuum jacket also serves as the exterior, making the product compact.
Product details
A one-second supply of warmed water kept in tank is convenient for customers. The compact design does not take up more storage space (pull-out type) .
Product specifications
| Model | Electric Instant Water Heater with Vacuum Bottle Structure |
|---|---|
| Product number | REQ02A |
| Water storage capacity | About 1.5 L |
| Rating (Voltage) | 100 VAC |
| Rating (Power consumption) | 350 W |
| Water supply system | End stop system (including relief valve) |
| Water heating time | About 19 minutes (to 75°C from 15°C) |
| Tapping temperature | Initial tapping temperature of about 38°C |
| Product weight (weight when the tank is full) | About 3.1 kg (about 4.6 kg) |
